Product Certification
UL Listed / FM Approved (EX 26523)
Material of Construction
Ductile Iron as per ASTM A536 Gr. 65 – 45 – 12
Pressure Rating
Test Pressure : 12.5 MPa
Max. Working Pressure : 2.5 MPa
Please note that as per FM 1920:2007 Sizes <= 150 mm are rated PN20 and > 150 mm are rated PN16
Nuts & Bolts
Heat Treated Carbon Steel as per ISO 898-1 Class 8.8
Finishing
Epoxy Red Paint RAL – 3000/3001
| Nominal Size | Nominal Size (Inch) | Pipe O.D. | L |
|---|---|---|---|
| 100×65 | 4×2.2/1 | 114.3×76.1 | 102 |
| 100×80 | 4×3 | 114.3×88.9 | 102 |
| 125×80 | 5×3 | 139.7×88.9 | 102 |
| 125×100 | 5×4 | 139.7×114.3 | 102 |
| 150×65 | 6×2.1/2 | 165.1×76.1 | 102 |
| 150×80 | 6×3 | 165.1×88.9 | 102 |
| 150×100 | 6×4 | 165.1×114.3 | 102 |
| 150×125 | 6×5 | 165.1×139.7 | 102 |
| 200×80 | 8×3 | 219.1×88.9 | 130 |
| 200×100 | 8×4 | 219.1×114.3 | 130 |
| 200×125 | 8×5 | 219.1×139.7 | 130 |
| 200×150 | 8×6 | 219.1×165.1 | 130 |
