Description
Salient Features
- Eliminates Theft Problem Being Low Resale Value.
- No Corrosion As Highly Corrosion Resistant.
- Excellent Finish Due To Investment Casting Robust
- Construction For Safety
- Excellent Durability & Low Maintenance
- Pull Out Type/ Quick Release Lug For Easy
- Operation
Product Description
Size : 63mm
Material : Stainless Steel
Inlet : 100mm NB Flanged as per IS: 1538
Outlet : Standard 63mm Female Instantaneous IS 5290 Type B
Approval : IS: 5290 Type B ISI Marked
Testing
Seat Test : 14 kg / cm2 for 2.5 minutes
Body Test : 21 kg / cm2 for 2.5 minutes
Flow Test : 1800 LPM @ 7 kg/ cm2
Working Pressure : Up to 10kg/cm2
Product Specifications
- BODY : SS 304 IS 3444 GR 1
- SPINDLE : SS (IS 6603) SS 304
- BONNET : SS 304 (IS 3444 GR 1)
- FEMALE INST. OUTLET : SS 304 (IS 3444 GR 1)
- HAND WHEEL : CAST IRON ( IS 210)
- Washer : Rubber IS : 937 Type A
- Spring : Stainless Steel Wire IS : 6258
Notes
1. Product images are for illustration purposes only. Actual product may vary.
2. Actual dimensions may change over time, due to continual design improvements. Please confirm before placing order.
