Description
Product Description
Size : 25mm
Inlet : 25mm Threaded
Outlet : 25mm x 30mtr Hose Reel Hose with Shut off Nozzle
Reference Standard : Manufacturer’s Standard
Testing
Hydrostatic Pressure Test : 21 kg / cm2 for 2.5 minutes ( For Drum Only)
Performance Requirements : 6 Meter Horizontal Throw at 7kg / cm2 with 40 LPM Water
Working Pressure : Up to 7kg / cm2
Product Specifications
- Hub : MS IS : 513
- Side Rim : MS IS : 513
- Swivel Joint : Metal Plated
- Hose Reel Tubing : Thermoplastic Hose as per IS : 12585 Type – 2 (ISI Marked)
- Shut Off Nozzle : Stainless Steel
Notes
1. Product images are for illustration purposes only. Actual product may vary.
2. Actual dimensions may change over time, due to continual design improvements. Please confirm before placing order.
