Description
Dimensions (in mm)
| Inch | mm | A | B |
|---|---|---|---|
| 1.1/4×1 | 32×25 | 40.1 | 42.4 |
| 1.1/2×1 | 40×25 | 41.9 | 45.7 |
| 1.1/2×1.1/4 | 40×32 | 46.2 | 47.8 |
| 2×1 | 50×25 | 43.9 | 51.3 |
Product Certification
UL Listed / FM Approved (EX 6624)
Material
ASTM A536
Threads
ASME B1.20.1
Pressure Rating
Test Pressure : 12.5 MPa
Max. Working Pressure : 2.5 MPa
| Inch | mm | A | B |
|---|---|---|---|
| 1.1/4×1 | 32×25 | 40.1 | 42.4 |
| 1.1/2×1 | 40×25 | 41.9 | 45.7 |
| 1.1/2×1.1/4 | 40×32 | 46.2 | 47.8 |
| 2×1 | 50×25 | 43.9 | 51.3 |
